Forum Index : Microcontroller and PC projects : How to order PCB - standard Pico2 HDMI
Page 1 of 2   |
|||||
| Author | Message | ||||
homa Guru  Joined: 05/11/2021 Location: GermanyPosts: 459 |
Hi Peter and guys, I am currently trying to order the "standard" board from you. https://www.thebackshed.com/forum/ViewTopic.php?TID=17301&P=4#228678 The How-to-order-PCB.txt says the following: Please refer to https://prodocs.easyeda.com/en/pcb/order-order-pcb/index.html On the website of easyeda.com I first try to import the ZIP as a project, but that doesn't work, neither in the easy nor in the pro version? The ZIP contains "only" Gerber files. On which page do I have to upload them to order assembled boards? I would appreciate a brief explanation and help so that I don't make any mistakes when ordering, thank you. Matthias |
||||
| matherp Guru Joined: 11/12/2012 Location: United KingdomPosts: 10062 |
Order from jlcpcb not easyeda |
||||
| twofingers Guru Joined: 02/06/2014 Location: GermanyPosts: 1526 |
Hi Matthias, are you looking for this: https://geoffg.net/Custom_PCBs.html ? Regards Michael PS: I also need a board. In case you want to order more than one. causality ≠ correlation ≠ coincidence |
||||
| homa Guru Joined: 05/11/2021 Location: GermanyPosts: 459 |
thx. I got it out and ordered it. Now it's time to wait ... @PilotPirx: Have a look at your PM about the CMM2 housing and possibly this one ... @Michael: When the order arrives, I'll get back to you. |
||||
| twofingers Guru Joined: 02/06/2014 Location: GermanyPosts: 1526 |
That was quick! causality ≠ correlation ≠ coincidence |
||||
| homa Guru Joined: 05/11/2021 Location: GermanyPosts: 459 |
Hello Peter, do you have a suitable dxf file? https://www.thebackshed.com/forum/ViewTopic.php?TID=17301&P=3#227926 Then I can use it to feed my little CNC (cheese milling machine ;-). hopefully without errors Matthias |
||||
| twofingers Guru Joined: 02/06/2014 Location: GermanyPosts: 1526 |
I'm confident. I'm still waiting for the intended use for my cheese milling machine (Genmitsu 3018-PROVer V2). It's been sitting unused for 3 years. I think it makes too much dirt in living spaces. Michael Regarding the front panel: isn't it easier to 3D print it? I imagine it would smell pretty bad to laser it. Edited 2024-12-09 04:22 by twofingers causality ≠ correlation ≠ coincidence |
||||
Mixtel90 Guru Joined: 05/10/2019 Location: United KingdomPosts: 7499 |
Front and rear panels can be made as PCBs. It works really well, and you can have any colour that's available as solder mask. :) I use 1.6mm board but take the copper off for a couple of mm right round the edges. That reduces the thickness slightly and helps prevent the solder mask from chipping when the board is cut up. Mick Zilog Inside! nascom.info for Nascom & Gemini Preliminary MMBasic docs & my PCB designs |
||||
disco4now Guru Joined: 18/12/2014 Location: AustraliaPosts: 971 |
Latest F4 Latest H7 FotS |
||||
| twofingers Guru Joined: 02/06/2014 Location: GermanyPosts: 1526 |
I got it!  Thank you Gerry! Kind Regards MIchael causality ≠ correlation ≠ coincidence |
||||
| homa Guru Joined: 05/11/2021 Location: GermanyPosts: 459 |
Hi Michael, can you load the dxf file? And if so, with which program? Unfortunately I get an error message that something in the file is wrong ... Matthias Fixed, the download was wrong. I have to download it as “raw”, save target as only puts garbage in the file :-( Edited 2024-12-10 04:07 by homa |
||||
| twofingers Guru Joined: 02/06/2014 Location: GermanyPosts: 1526 |
Fusion 360. But you found already a solution. Great!  Michael causality ≠ correlation ≠ coincidence |
||||
| homa Guru Joined: 05/11/2021 Location: GermanyPosts: 459 |
.jpg) .jpg) Front housing and cnc with plastic are not compatible, I prefer to stick to milling wood with my modest skills. Now I have to find someone with a laser ... The order and completion of the project are completed so far. Matthias @Michael (twofingers): Noch Interesse an einem kompletten Bausatz (Board, rp2350, Gehäuse)? Dann schreibe eine PN. Löten und die Fronten musst du selber machen oder ich finde die Tage noch jemanden mit Laser. Still interested in a complete kit (board, rp2350, housing)? Then write me a PN. You'll have to do the soldering and the fronts yourself or I'll find someone with a laser in the next few days. |
||||
| matherp Guru Joined: 11/12/2012 Location: United KingdomPosts: 10062 |
It can work OK. You need a 2mm single flute bit and turn it quite slowly |
||||
| twofingers Guru Joined: 02/06/2014 Location: GermanyPosts: 1526 |
Hi Matthias, I am very happy about the offer! You got a PM. Kind regards Michael causality ≠ correlation ≠ coincidence |
||||
| Frank N. Furter Guru Joined: 28/05/2012 Location: GermanyPosts: 935 |
@homa: Hi Matthias, Do you perhaps still have a kit left? Kind regards and Merry Christmas (to all) Frank |
||||
Martin H. Guru Joined: 04/06/2022 Location: GermanyPosts: 1192 |
Matthias if you actually have one left, please let me know Cheers Martin PS: Maybe it would be enough if I printed the front panel 'no comment |
||||
| Mixtel90 Guru Joined: 05/10/2019 Location: United KingdomPosts: 7499 |
If you print the front panel, laminate it and cut it out neatly it can often cover slightly oversize holes in the plastic. I've done this before and it worked ok. For this sort of case you really need to stick the print down then trim it so about 0.5mm of plastic shows top anb bottom and about 1mm at each end. Any reasonable double sided tape is fine. Mick Zilog Inside! nascom.info for Nascom & Gemini Preliminary MMBasic docs & my PCB designs |
||||
| homa Guru Joined: 05/11/2021 Location: GermanyPosts: 459 |
Hi Frank and Martin, I won't know myself until next week after the holidays. I'll get back to you on Monday. I'm sorry that I can't be more specific yet. Happy and blessed holidays to all! Matthias |
||||
| Martin H. Guru Joined: 04/06/2022 Location: GermanyPosts: 1192 |
Yes, there are various good options for creating the front panels. I was thinking of 3d printing instead of milling and drilling. You can also get a label by changing the filament for the last 2 layers. Happy christmas holidays Martin (Pensioners from 2025)  T-shirt, my daughter gave me as a present Edited 2024-12-24 23:44 by Martin H. 'no comment |
||||
